Description

About the Bravo TARAC®

_____________________________

Overview

The Bravo TARAC is a prism that optically adds elevation to any scope to exceed its native travel.  Two models are available:  Ultra-light and Magnetic.

_____________________________

Advantages

• Light-weight.
• Add 30 or 60 MRAD (100 or 200 MOA) to any riflescope with a single optic; saves weight.
• Stack prisms or flip¹ the magnetic to increase range.
• Detachable mount

¹ Inverting a 30 MRAD magnetic Bravo, paired with a 30 MRAD rail and scope, unlocks 0-90 MRAD (300 MOA) of adjustment:
+30 Rail – 30 Bravo (inverted) = 0 MRAD
+30 Rail = 30 MRAD
+30 Rail + 30 Bravo (upright) = 60 MRAD
* Run the scope to dial +30 more MRAD in each configuration

_____________________________

Disadvantages

• Susceptible to optical interference from a barrel or heat since the scope centerline remains constant.
• Limited to 60 MRAD (200 MOA) due to color separation from chromatic aberration.

*Upgrade to the Charlie TARAC® to increase the scope centerline, add more elevation, and eliminate chromatic aberration.

_____________________________

Attachment

+ Rail – Toolless Bobro quick-detach.  Optimized to mount directly in front of scopes on 1.5″ scope rings.  Works with scopes on canted rails up to 10 MRAD (40-MOA).
+ Scope – Attaches directly to the scope’s objective (not a sunshade).  Scope mounts are scope specific, requires 0.25″ (6 mm) clearance, and a digital level or Plumb Bob for initial setup.

_____________________________

Specs

Ultra-Light
Dimensions (H x W x D):
3.1″ x 2.6″ x 2.4″ (79 x 65 x 60 mm)
Weight Option 1:
30 MRAD (100 MOA) | 7.0 oz (198g)
Weight Option 2:
60 MRAD (200 MOA) | 9.8 oz (278g)

Magnetic
Dimensions (H x W x D):
3.2″ x 3.5″ x 2.6″ (81 x 88 x 65 mm)
Weight Option 1:
30 MRAD (100 MOA)
Rail mount 10.2 oz (289g)
Scope mount 12.2 oz (343g)
Weight Option 2:
60 MRAD (200 MOA)
Rail mount 13.0 oz (369g)
Scope mount 15.0 oz (425g)

Mount:
ADM (MIL-STD-1913 rail) or scope mount
Night Vision Compatibility:
Yes
Thermal Compatibility:
No (See Charlie TARAC)
Electronics:
None
Country of Origin:
100% Made in the USA
Manufacturing Method:
Billet
Warranty:
5 year (Non-transferable)

_____________________________

Performance

Salt Water Resistance:
16ft (5m) depth
Operating Temperate:
-40°F to 140°F (-40°C to 60°C)
Fog Resistance:
Yes
Anti-Reflective Coating:
Yes

_____________________________

Included in the Box

+ Optic
+ ADM QD or scope mount (per selection)
+ Desiccant bag

_____________________________

User Guide

PDF Download (coming soon)
